The Cygnus 6+ PRO Ultrasonic Thickness Gauge by Cygnus Instruments is a high-precision, rugged device designed for industrial thickness measurement in demanding environments. With multi-mode capabilities (Multiple-Echo, Single-Echo, Echo-Echo), it excels in applications requiring measurements through coatings, corrosion, or on composites. Compliant with MIL-STD-810G for shock, vibration, and extreme temperatures, it is ideal for oil & gas, aerospace, and marine industries.
Key Features:
- Multi-Mode Measurement:
- Multiple-Echo: Measures through coatings up to 20mm thick without removal.
- Echo-Echo: Ideal for painted metals with back-wall corrosion (1mm coating tolerance).
- Single-Echo: Effective on uncoated metals, cast materials, plastics, and composites.
- Advanced Imaging: Live A-scan display, rolling B-scans, and freeze function for real-time analysis.
- Robust Design: IP67-rated, explosion-safe (Class I, Division 2), and tested for immersion (1m/30min).
- Data Logging: Stores 500,000+ measurements with A/B-scan data on SD cards; Bluetooth for wireless transfer.
- Cyglink Software: Generates PDF/Excel reports, analyzes A/B-scans, and manages data on Windows.
- High Accuracy: ±0.1mm or 0.1% of measurement; MSI™ technology ensures stable readings.
Specifications Highlights:
- Probes: Single/twin crystal options (6mm–19mm diameter, 2.25–5MHz frequencies).
- Measurement Range: 0.8–250mm (steel).
- Display: Dual screens (2.4″ LCD + rotatable OLED) for sunlight readability.
- Battery: 10+ hours runtime (3xAA).
- Operating Temperature: -10°C to 55°C.
- Warranty: 3 years (gauge), 6 months (probes).
Standard Kit Includes:
- Gauge, carry case, probes (varies), couplant, test block, batteries, USB cable, and accessories.
